Casting Process revolutionized by Click2Cast

| Editor: Janina Seit

Altair Engineering and Solid Thinking presented the new Click2Cast 2018 release as a world premiere at Euroguss, which took place in Nuremberg from January 16 to 18, 2018. Powerful geometry creation and modeling capabilities have been added to the software, allowing users to design and optimize the entire casting process on a single platform.

Related Companies

"Click2Cast is recognized worldwide for being fast, simple, accurate and cost-effective." said Ravi Kunju, Vice President of Manufacturing Solutions at Altair
( Source: Pixabay / CC0 )

With the release of Click2Cast, designers and development engineers will be able to communicate on a common working platform for the first time. It offers a wide range of tools. With this tool, components can be modified, porous areas identified and remedial feeders and sheaths as well as cooling ducts can be created. In addition, the complete development process of high-quality components can be evaluated and improved.

"Click2Cast is recognized worldwide for being fast, simple, accurate and cost-effective. That's why it was very important for us to achieve a balance between usability and functionality in this latest release," said Ravi Kunju, Vice President of Manufacturing Solutions at Altair. “We are very pleased that we didn’t have to make any compromises, even though we have added powerful features. The approach of using our Solid Thinking Inspire Framework to advance the use of simulation tools to an early design stage had a huge impact on the construction scene. Now we do the same with casting simulation by introducing Click2Cast into the same environment as Inspire. Our development teams have worked very hard and have done a great job on both our solvers and the user interface. We are convinced that the user experience will inspire users even more."

Click2Cast revolutionizes the casting process with its powerful new geometry tools designed specifically to produce sprue systems, feeders, casings, coolers and cooling channels on a single platform.
Click2Cast revolutionizes the casting process with its powerful new geometry tools designed specifically to produce sprue systems, feeders, casings, coolers and cooling channels on a single platform.
( Source: Altair )

Combining Powerful Functionality with Affordability

The official release of the new version is planned for March 2018, but visitors of the Euroguss were able to get a first impression of its powerful functions. The new version offers significant improvements:

  • Completely new user interface based on the Inspire Framework with powerful geometry creation and modeling capabilities
  • Possibility of modelling and rapid modification of sprue systems, feeders, coolers, overflows and sheaths (iso- and exothermic)
  • Automatic generation of core geometries (export ready for 3D printing)
  • One-click solidification simulation
  • Advanced visualization functions including flow front temperature development
  • Dynamic and multiple partial sections of the view plane
  • Support of various file formats (CAD-native)

“I've never seen anything comparable or even similar before and I'm really looking forward to making it available to my customers," says Howard Weinberg, founding partner of Spot Technologies. This new Click2Cast generation is indeed a groundbreaking innovation. Thanks to a combination of powerful functionality and affordability, the tool has quickly paid for itself. Even for occasional users, the easy handling of Click2Cast makes it possible to explore modern simulation tools. This provides an even larger user base with access to a technology that was previously unavailable to them and thus supports the entire supply chain in the development process.

New Functions: Sprue Modeling and Modeling of Cooling Sections

“Click2Cast is constantly being upgraded with new functionalities and can be used in more and more complex applications. However, the user interface remains industry-specific and is always easy to use. When new features are added, or a new upgrade is released, this can be a real challenge," says Òscar Íñigo, Die Casting Consultant, Inytial Go.

“Let’s for instance take sprue modeling or cooling line modeling, both of which are new features of this release, Solid Thinking has demonstrated its commitment to delivering the best software. Both extensions are simply great! Click2Cast 2018 will be well received by casting specialists and foundry technicians."
