Reaching Optimum Properties: Heat and Surface Treatment in the Die Casting Industry

| Author / Editor: EUROGUSS / Janina Seit

Die-casting processes enable the cost-effective production of narrowly tolerated parts that have many beneficial characteristics. In certain cases, it is possible to optimize the mechanical properties even further by means of heat and surface treatment procedures.

Related Company

Reaching optimum properties: Heat and surface treatment in the die casting industry
( Source: Pixabay / CC0 )

Die-cast parts which are manufactured in the conventional manner are considered to be not heat-treatable, or only with difficulty. The reason is that gases are dissolved or trapped in the molten metal. When such cast parts are heated up to higher temperatures which are necessary for heat treatment operations, these gases expand and form bubbles with a negative impact on the mechanical strength and the dimensional accuracy of the parts. A way out is offered by procedures such as vacuum diecasting [1] and laminar die-casting.

Precipitation Hardening

Parts which are made of heat-treatable alloys and produced with the mentioned procedures can be heat-treated. It is characteristic for the vacuum die-casting procedure that all areas of a casting machine which are reached by the melt are evacuated. Also the gases which arise when the melt flows in are continuously exhausted by a vacuum. When using the laminar die-casting process, on the other hand, a relatively low mould filling speed prevents that gases are trapped. The cast parts are annealed according to a time-temperature-profile which depends on the alloy and the dimensions. In this way, a homogeneous solid solution is generated in the parts. After a certain annealing time, the parts are quenched in water and in some cases re-annealed once more. This procedure is called T6 heat treatment [2 and 3]. After the first annealing process, the solution annealing, the solid solution is supersaturated with alloying atoms. A longer ageing of the parts at room temperature or at elevated temperatures has the effect that the surplus alloying atoms diffuse out from the solid solution, accumulate in certain boundary zones and form intermetallic compounds.

During this process called precipitation hardening, the hardness and the mechanical strength of the microstructure and therefore also of the cast parts increase [4].

Aluminium in Competition With Cast Iron

The Franken Guss foundry company based in Kitzingen, Gemany, which is specialized in iron and aluminium casting, uses the laminar die-casting process among other things for the manufacture of crank-case covers for large diesel engines. These covers are made of the curable aluminium casting alloy AlSi10Mg and undergo a T6 heat treatment process. Therefore, they have mechanical properties corresponding to those of the original parts that were made of ductile cast iron, but on top of that they are about 40% lighter (Fig. 1).

Fig. 1: The covers are made of the curable aluminium casting alloy AlSi10Mg and undergo a T6 heat treatment process.
Fig. 1: The covers are made of the curable aluminium casting alloy AlSi10Mg and undergo a T6 heat treatment process.
( Source: FrankenGuss )

Also certain magnesium alloys are curable [2]. In many cases, however, a heat treatment process is unnecessary because a

fine-grained microstructure is generated during the casting process due to the high cooling speed. This gives the cast parts very favourable mechanical properties. Zinc parts manufactured by die-casting undergo a microstructure modification at room temperature caused by separation processes. The modification is linked with a decrease of the mechanical strength. This natural ageing effect is to be considered when designing such parts and can be anticipated with a heat treatment process [5].

Slight Grinding and Other Surface Treatment Procedures

Fig. 2: A working piece treated by slight grinding with polished surface.
Fig. 2: A working piece treated by slight grinding with polished surface.
( Source: Spaleck Oberflächentechnik GmbH & Co. KG )

The surface of a workpiece is particularly subjected to external loads, for example wear and corrosion. Several procedures for the surface treatment such as slight grinding, galvanic coating and powder coating are offered to refine the surfaces of die-cast parts with a view to their subsequent function or in accordance with aesthetic aspects. The slight grinding process is very frequently used for die-cast parts. The functional principle is that the parts are filled into a vibrating tub where they come into shaking contact with abrasive grinding chips supported by aqueous substances. Like pebbles in a riverbed, which grind themselves mutually and get rounded, the cast parts are deburred and their edges rounded off. The process can be carried out relatively easy, requires only short processing times and generates a high surface quality (Fig. 2) [6].

References

  • [1] Druckguss aus NE-Metallen. Technische Richtlinien. Hrsg. Verband Deutscher Druckgießereien (VDD) und Bundesverband der Deutschen Gießerei-Industrie (BDG): Düsseldorf 2016, S. 36
  • [2] Klaus Herfurth et al.: Giessereitechnik kompakt. Werkstoffe, Verfahren, Anwendungen. Düsseldorf 2013, S. 65f; S. 55-57
  • [3] Daniel H. Herring: Heat Treating of Aluminum Castings. in: IndustrialHeating.com, Februar 2010, S. 22
  • [4] Wärmebehandlung von Aluminiumlegierungen. Hrsg. Gesamtverband der Aluminium-Industrie e.V. (GDA), Merkblatt W7, S. 10 ff http://www.aluinfo.de/files/_media/dokumente/Downloads/Technische%20Daten/Merkblaetter/W7_Waermebehandlung_von_Aluminiumlegierungen.pdf
  • [5] Walter Leis, Lothar H. Kallien: Alterungsvorgänge bei Zinkdruckgusslegierungen. in: Horizonte, Zeitschrift für die Forschung an den Hochschulen für Angewandte Wisssenschaften in Baden Württemberg, Nr. 38, September 2011, S. 24 – 27. http://gta.htwaalen.de/de/publikationen/pdfs/Zinkalterung_Horizont_Sept11.pdf
  • [6] Karin Geukes, Ingo Löken: Individuelle Oberflächenbehandlung für bessere Druckgussqualität. in: Giesserei 09/2012, S. 68-71
