Physical Life Cycle Assessment Simulation-based Calculation of the Environmental Impact of Zinc Die Casting When Using Primary and Secondary Raw Materials for Alloy Production

From Nicole Kareta

Physical life cycle assessment offers the possibility of identifying optimization potential in the manufacturing process, e.g. for reducing energy use and thus avoiding CO2 and other greenhouse gases. This report describes the physical life cycle assessment for the recycling of zinc scrap with the aim of producing zinc alloys for use in zinc die casting.

Related Companies

Physical life cycle assessment can help to identify optimization potential to reduce the environmental impact.
Physical life cycle assessment can help to identify optimization potential to reduce the environmental impact.
(Source: gemeinfrei / Pexels )

Life cycle assessment (LCA) of products is often carried out according to the standards of the 14000 series. Just as often, generic data for raw materials and energy are used for this purpose in some areas. An accurate, product-specific assessment can only be made using a simulated balance sheet based on the manufacturing process. This type of balance, also known as a physical life cycle assessment, offers the possibility of identifying optimization potential in the manufacturing process, e.g. for reducing energy use and thus avoiding CO2 and other greenhouse gases. This report describes the physical life cycle assessment for the recycling of zinc scrap with the aim of producing zinc alloys for use in zinc die casting. The physical data from the digital twin of a zinc recycling or remelting plant and the mapping of the zinc die casting processes provide information on the CO2-footprint in the supply chain of the recycling raw material up to the finished casting.

The careful use of resources and the sustainable implementation of a circular economy are starting points for sustainable products. A number of terms such as EcoDesign, Cradle-to-Cradle and efforts towards the reuse of products and materials determine the current debate on sustainable climate protection. Each of these terms considers the amount and type of energy used in the manufacturing processes in the supply chain of a product, during its use, and in the recycling of a material. The focus is on materials that are suitable for being processed into a product with the greatest possible benefit using little energy and that are also suitable for being used again after an appropriate or long period of use - and again with a favorable energy balance.

The material zinc makes this scenario possible - it can be used in a variety of ways and has the appropriate material properties for the use of technological products in the sectors automotive / mobility, electrical engineering, steel and infrastructure construction, architecture, medical technology, pharmaceuticals, health, food, household, etc. - Zinc is used because of its excellent possibilities to be deconstructed and recycled. Zinc is "used" and not "consumed".

For the implementation of these goals, various considerations are drawn upon. In addition to key figures on recycling rates for a material and recyclate content in products, the life cycle assessment is an instrument for illustrating the environmental impact of products. In the future, life cycle assessments will become an increasingly important decision-making basis for investors, purchasers, project decision-makers, etc., in order to make a material selection for a specific component, for products, plants and other major projects.

To optimally design supply chains and production processes, it is imperative to rigorously map these supply chains with simulation tools to generate physics-based environmental data.

Environmental Impact Supply Chain - Alloy / Zinc Die Casting

The presentation of the environmental impact of zinc alloys in the supply chain of zinc die casting with the method of simulation-based, physical life cycle assessment allows, among other things, the presentation of the difference in the environmental impact of zinc alloys based on SHG fine zinc (special-high-grade / primary zinc) compared to secondary zinc (recycled zinc) with defined proportions of recyclate. In order to optimize supply chains and production processes, it is imperative to rigorously map these supply chains with simulation tools in order to generate physics-based environmental data. Environmental balance has been created with the simulation program HSC-SIM, which unlike life cycle assessments according to EN 14040 or environmental product declarations (EPD) according to EN 15804, offers the possibility to show a balance of the entire supply chain from primary zinc / secondary zinc and the zinc die casting process to the surface treatment / passivation of zinc die castings. For this purpose, the simulation program maps a "digital twin" of the processes with the specific energy consumption data and the resulting greenhouse gas (GHG) emissions. [Figure 1, 4-7] This methodology has been successfully applied several times in various processes for the production of metals in different industries in the field of Circular Economy [2-5]. The data obtained can be used to generate a product EPD if required. The result provides information on the CO2 footprint (GWP) and other environmental impacts (EP, AP, POCP, see Table 1) for primary and secondary materials. This study was carried out by the Initiative ZINK with the support of Prof. Dr. Dr. h.c. mult. Markus A. Reuter, TU Bergakademie Freiberg, and the companies REAZN S.A., Luxembourg and Adolf Föhl GmbH + Co KG, Rudersberg.

Subscribe to the newsletter now

Don't Miss out on Our Best Content

By clicking on „Subscribe to Newsletter“ I agree to the processing and use of my data according to the consent form (please expand for details) and accept the Terms of Use. For more information, please see our Privacy Policy.

Unfold for details of your consent

Life cycle assessment and methodology

Life cycle assessment (LCA) has established itself in recent decades as an important tool for the ecologically oriented planning and design of products and will play an important role in the evaluation of materials and products in the future. As a scientifically based tool, it allows a comprehensive assessment and thus an optimization of the environmental impact. The essential characteristics of LCA include the consideration of the environmental impact, extended by the view of the entire life cycle, from the extraction of a raw material to its disposal or preparation for reuse of the material. In LCA, all relevant environmental impacts are considered, as far as quantifiable. The preparation of a life cycle assessment is usually carried out in several steps, and the ISO 14040 system has become internationally accepted.1)

In this study, a simulation methodology was used for LCA, [1-5] which allows a process-based consideration of the environmental impact. Recycling of metals occupies a key position in securing resources for maintaining and expanding technologies and infrastructure in the future. With regard to the issue of the use of secondary raw materials for zinc die casting, no life cycle assessment studies exist to date. The simulation methodology used, with the software HSC-SIM2), version 10.2, makes it possible to carry out time-realistic calculations of the impact categories in the material production of zinc alloys and subsequent processing in the die casting process based on specific production conditions, instead of generic data.

The advantage of this simulation methodology lies in the possibility of updating the data at any time with the support of a digital twin of the production processes. This means that the performance and the improvement or deterioration of the environmental impact of a production process can be shown virtually at the push of a button. In addition, the simulation can be used to calculate variants / scenarios, for example, to check the effects of changes in the process or the implementation of innovations and investments in production for their environmental impact (impact categories, GHG emissions). This type of environmental impact accounting is a suitable tool to accompany the goal of reducing CO2 and other impact categories on the way to CO2 neutrality. The concept of CO2 neutrality "avoid - reduce - compensate" can be followed. The simulation methodology provides a suitable tool to follow this concept down to the details of the manufacturing process and to plan and implement appropriate measures. It also shows at which point in the process the use of renewable energy has the greatest effect on the footprint. However, it also shows the limits of supposedly sensible investments and innovations in the circular economy as well as the thermodynamically determined limits.

Figure 1: Linked base metal flow diagrams with environmental footprint analysis - HSC-SIM Model.
Figure 1: Linked base metal flow diagrams with environmental footprint analysis - HSC-SIM Model.
(Source: Initiative ZINK/Prof. M. A. Reuter)

System Boundaries

The HSC-SIM software for simulation-based engineering as a digital twin allows the individual inclusion of all production steps (Fig. 4-7) including the energy input and output as well as the performance parameters of the production units, related to the unit ton / zinc alloy. In the study, the following production processes have been considered as the system boundary. The calculations performed are partly based on GIBBS-free energy minimization.

Environmental Impact of Primary Zinc (SHG)

Use of available LCA data on primary zinc and the zinc alloys ZAMAK primary alloy (e.g. IZA) using the assumption of an energy mix according to GaBi database.

Environmental Impact Secondary Zinc Alloys

Impact parameters:

  • Transport of zinc scrap to remelting plant REAZN S.A. based on collected logistic data (distances, type of truck small size / large volume) from scrap suppliers -Scope 3
  • Internal transports (forklifts gas powered / electric, cranes) - Scope 1
  • General electricity -Scope 2
  • Production energy (electricity mix Belgium) -Scope 1
  • Fuels (diesel) -Scope 1
  • Individual energy output of equipment -Scope 1

The values for active parameters mentioned in Figures 4-7 are kept confidential and are hidden in the tables of the figures. The output data of the processes are shown in the result evaluation (Table 1).

Environmental Impact Zinc Die Casting Production

  • Transport of zinc alloy from the remelting plant REAZN S.A. to the zinc die casting plant Adolf Föhl GmbH on the basis of collected logistic data (distances, type of truck small/large volume) -Scope 3
  • Internal transports (forklift gas / electric, cranes) -Scope 1
  • Electricity in general -Scope 2
  • Production energy (EU 28 electricity mix) -Scope 1
  • Individual energy output of equipment -Scope 1

Fig. 2: Secondary zinc production processes.
Fig. 2: Secondary zinc production processes.
(Source: Initiative ZINK)

Fig. 3: Zinc casting production processes.
Fig. 3: Zinc casting production processes.
(Source: Initiative Zink)

Results Analysis

Table 1: Comparison of environmental impact primary zinc/ secondary zinc.
Table 1: Comparison of environmental impact primary zinc/ secondary zinc.
(Source: Initiative Zink)

Figure 4: Process and results diagram for melting furnace F5 incl. accompanying peripheral processes (Scope 1 to 3). The information on effective parameters given in the figure has been treated confidentially and hidden.
Figure 4: Process and results diagram for melting furnace F5 incl. accompanying peripheral processes (Scope 1 to 3). The information on effective parameters given in the figure has been treated confidentially and hidden.
(Source: Initiative ZINK/Prof. M. A. Reuter)

Fig. 5: Process and results diagram for melting furnace F2 incl. accompanying peripheral processes (Scope 1). The information on effective parameters given in the figure has been treated confidentially and is hidden.
Fig. 5: Process and results diagram for melting furnace F2 incl. accompanying peripheral processes (Scope 1). The information on effective parameters given in the figure has been treated confidentially and is hidden.
(Source: Initiative ZINK/Prof. M. A. Reuter)

Figure 6: Process and result diagram for melting furnace DC1 in a zinc die casting production including accompanying peripheral processes (Scope 1 to 3). The information on effective parameters given in the figure has been treated confidentially and is hidden.
Figure 6: Process and result diagram for melting furnace DC1 in a zinc die casting production including accompanying peripheral processes (Scope 1 to 3). The information on effective parameters given in the figure has been treated confidentially and is hidden.
(Source: Source: Initiative ZINK/Prof. M. A. Reuter)

Figure 7: Process and result illustration of a zinc die casting production and surface passivation in the nano-coating process (Scope 1 to 3).
Figure 7: Process and result illustration of a zinc die casting production and surface passivation in the nano-coating process (Scope 1 to 3).
(Source: Initiative ZINK/Prof. M. A. Reuter)

The analysis of the production steps of primary zinc/secondary zinc and zinc die casting (possibility of surface passivation excluded) on the basis of environmentally relevant real data shows for the first time the environmental impact of the entire supply chain of zinc die casting products. The results provide a concrete overview of the interrelationships of energy consumption and show the most effective areas for action in the process to reduce energy consumption. By simulating changes in the manufacturing processes with the HSC-SIM software, such as the use of more energy-efficient equipment or a change in the energy mix with shares of renewable or alternative energy, the impact of investments to improve the environmental footprint can be illustrated. The simulation allows a direct comparison between the existing production process and future changes, also with regard to the financial impact of an investment on the environmental impact - an investment can thus be mapped in the environmental balance sheet or in a sustainability report based on real data.

For the zinc die casting supply chain, a revealing picture emerges of the energy intensity in the individual production stages. In the current study, the status of the complete production process including upstream raw material production is mapped. Both the use of primary raw materials for zinc die casting alloys and the use of secondary zinc are calculated. As a result, the use of 100 % secondary zinc for zinc alloys in the REAZN S.A. plant with its specific production and energy parameters reduces the CO2 footprint by up to 97.5 % compared to the use of primary zinc (SHG zinc). This value can be further optimized in the future using the HSC-SIM software. Developments in the environmental balance over a period of time can hereby be efficiently used for sustainability reporting and the corporate carbon footprint (CCF) - any change can be versioned in the software. The digital twin of production contributes to a further implementation of Industry 4.0 and digitalization as well as the provision of production data for a sustainability assessment.

Summary

A consideration of the production processes of zinc recycling for the production of alloys for reuse in zinc die casting with the aid of the software-supported creation of a physical life cycle assessment using the example of the companies REAZN S.A, and Adolf Föhl GmbH & Co. KG gives a view of the actual environmental impact of the supply chain. The processing of consumption data in the consideration of indirect and direct energy consumption (Scope 1 to Scope 3) is a unique possibility to determine the potentials for avoiding energy use, process improvements with an ecological balance effect as well as the real environmental footprint of a product in a process-related manner. For zinc die casting alloys from the recycling of zinc scrap, a company-related reduction of the environmental footprint in terms of e.g. CO2 of 97.5 % compared to the primary material is obtained. This value can be assumed as an initial value for further simulation of company-related process improvements. The digital mapping of the production processes offers the possibility to map process variants and to conduct business games, e.g. for planned investments in the production process. Based on a multi-recycling of zinc, there is a production-specific and comprehensive savings potential for energy and the resulting greenhouse gases. Furthermore, the recurring use of zinc scrap in its processing as a high-quality recycling raw material relativizes the overall balance for the environmental impact of extracted zinc from ores.

Preparation - Sources - References

This study was commissioned by the Initiative ZINK and prepared by Prof. Dr. Markus Reuter; Professor at the TU Bergakademie Freiberg, on the basis of specific real data from the companies REAZN S.A, Luxembourg, and Adolf Föhl GmbH & Co.KG, Rudersberg. All data sources have been incorporated into this study as of June 2020 to March 2021. The right to make changes in the presentation is reserved.

Sources and References:

  • 1)Ernst & Sohn, DGNB, IBU: Was jeder im Bauwesen über Ökobilanzen wissen sollte, p. 136
    2)Software-Reference: HSC Chemistry 10, Metso Outotec 1974-2021, www.mogroup.com
    3)M.A. Reuter, R. Matusewicz, A. van Schaik (2015): Lead, Zinc and their Minor Elements: Enablers of a Circular Economy, World of Metallurgy – ERZMETALL 68 (3), 132-146.
  • M.A. Reuter, A. van Schaik, J. Gediga (2015): Simulation-based design for resource effi-ciency of metal production and recycling systems, Cases: Copper production and recy-cling, eWaste (LED Lamps), Nickel pig iron, International Journal of Life Cycle Assess-ment, 20(5), 671-693.
  • M.A. Reuter (2016): Digitalizing the Circular Economy - Circular Economy Engineering defined by the metallurgical Internet of Things-, 2016 TMS EPD Distinguished Lecture, USA, Metallurgical Transactions B, 47(6), 3194-3220
  • Abadías Llamas, N. Bartie, M. Heibeck, M. Stelter, M.A. Reuter (2020). Simulation-based exergy analysis of large circular economy systems: Zinc production coupled to CdTe photovoltaic module life cycle. Journal of Sustainable Metallurgy, 6(1), 34-67.
  • N. Bartie, A. Abadías Llamas, M. Heibeck, M. Fröhling, O. Volkova, M.A. Reuter (2020). The simulation-based analysis of the resource efficiency of the circular economy – the enabling role of metallurgical infrastructure. Mineral Processing and Extractive Metallurgy (TIMM C) 129, 2, 229–249.
